Setting up LVM on three SCSI disks

For this recipe (Ubuntu 22.04 focal), the setup has three SCSI disks that will be put into a logical volume using LVM. The disks are at /dev/sda, /dev/sdb, and /dev/sdc (ignore the OS disk).

Disk /dev/nvme0n1: 1.76 TiB, 1920383410176 bytes, 3750748848 sectors
Disk model: SAMSUNG MZQL21T9HCJR-00A07
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 131072 bytes / 131072 bytes
Disklabel type: dos
Disk identifier: 0x0edc49ab

Device Boot Start End Sectors Size Id Type
/dev/nvme0n1p1 2048 8390655 8388608 4G 82 Linux swap / Solaris
/dev/nvme0n1p2 8390656 10487807 2097152 1G 83 Linux
/dev/nvme0n1p3 10487808 3750746799 3740258992 1.8T 83 Linux

Disk /dev/sda: 7.28 TiB, 8001563222016 bytes, 15628053168 sectors
Disk model: HGST HUH721008AL
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: 5DDAA99D-057D-5A45-90FF-C9DC826FCE7D

Disk /dev/sdb: 7.28 TiB, 8001563222016 bytes, 15628053168 sectors
Disk model: HGST HUH721008AL
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: 0A481C8C-79A2-0347-94EA-B2DF6361BF5F

Disk /dev/sdc: 14.57 TiB, 16000900661248 bytes, 31251759104 sectors
Disk model: ST16000NM003G-2K
Units: sectors of 1 * 512 = 512 bytes
Sector size (logical/physical): 512 bytes / 4096 bytes
I/O size (minimum/optimal): 4096 bytes / 4096 bytes
Disklabel type: gpt
Disk identifier: E1266E34-E31B-DF45-BC60-9D5565C11BC8



First, we need to clean the drives:

root@server ~ # wipefs -a /dev/sda
/dev/sda: 8 bytes were erased at offset 0x00000200 (gpt): 45 46 49 20 50 41 52 54
/dev/sda: 8 bytes were erased at offset 0x74702555e00 (gpt): 45 46 49 20 50 41 52 54
/dev/sda: 2 bytes were erased at offset 0x000001fe (PMBR): 55 aa
/dev/sda: calling ioctl to re-read partition table: Success
root@server ~ # wipefs -a /dev/sdb
/dev/sdb: 8 bytes were erased at offset 0x00000200 (gpt): 45 46 49 20 50 41 52 54
/dev/sdb: 8 bytes were erased at offset 0x74702555e00 (gpt): 45 46 49 20 50 41 52 54
/dev/sdb: 2 bytes were erased at offset 0x000001fe (PMBR): 55 aa
/dev/sdb: calling ioctl to re-read partition table: Success
root@server ~ # wipefs -a /dev/sdc
/dev/sdc: 8 bytes were erased at offset 0x00000200 (gpt): 45 46 49 20 50 41 52 54
/dev/sdc: 8 bytes were erased at offset 0xe8d7ffffe00 (gpt): 45 46 49 20 50 41 52 54
/dev/sdc: 2 bytes were erased at offset 0x000001fe (PMBR): 55 aa
/dev/sdc: calling ioctl to re-read partition table: Success

Now we can pvcreate:

root@server ~ # pvcreate /dev/sda
Physical volume "/dev/sda" successfully created.
root@server ~ # pvcreate /dev/sdb
Physical volume "/dev/sdb" successfully created.
root@server ~ # pvcreate /dev/sdc
Physical volume "/dev/sdc" successfully created.

pvs:

root@server ~ # pvs
PV VG Fmt Attr PSize PFree
/dev/sda lvm2 --- <7.28t <7.28t
/dev/sdb lvm2 --- <7.28t <7.28t
/dev/sdc lvm2 --- 14.55t 14.55t

Create a volume group

root@server ~ # vgcreate vg00 /dev/sda /dev/sdb /dev/sdc
Volume group "vg00" successfully created

root@server ~ # vgdisplay vg00
--- Volume group ---
VG Name vg00
System ID
Format lvm2
Metadata Areas 3
Metadata Sequence No 1
VG Access read/write
VG Status resizable
MAX LV 0
Cur LV 0
Open LV 0
Max PV 0
Cur PV 3
Act PV 3
VG Size <29.11 TiB
PE Size 4.00 MiB
Total PE 7630353
Alloc PE / Size 0 / 0
Free PE / Size 7630353 / <29.11 TiB
VG UUID CTRQ1a-MlEv-bFZy-7Ph9-eo0Q-mEQU-BBCewT

Tt is time to create one or more logical volume on top of the volume group. I’ll create a 500GB volume for system backups, and the remaining space will be used to create a second volume for media files. The -n option is used to indicate a name for the LV, whereas -L sets a fixed size and -l (lowercase L) is used to indicate a percentage of the remaining space in the container VG.

root@server ~ # lvcreate -n vol_backups -L 500G vg00
Logical volume "vol_backups" created.
root@server ~ # lvcreate -n vol_media -l 100%FREE vg00
Logical volume "vol_media" created.

lvsdisply:

root@server ~ # lvdisplay
--- Logical volume ---
LV Path /dev/vg00/vol_backups
LV Name vol_backups
VG Name vg00
LV UUID 4ULTFr-JTum-tOXD-byLF-FvCz-UzwJ-UsGnfq
LV Write Access read/write
LV Creation host, time server.darkq.net, 2023-05-10 17:15:43 +0200
LV Status available
# open 0
LV Size 500.00 GiB
Current LE 128000
Segments 1
Allocation inherit
Read ahead sectors auto
- currently set to 256
Block device 253:0

--- Logical volume ---
LV Path /dev/vg00/vol_media
LV Name vol_media
VG Name vg00
LV UUID FubLXZ-3fPe-A9fP-HYdl-eauq-vSsi-Ls3JJA
LV Write Access read/write
LV Creation host, time server.darkq.net, 2023-05-10 17:17:23 +0200
LV Status available
# open 0
LV Size <28.62 TiB
Current LE 7502353
Segments 3
Allocation inherit
Read ahead sectors auto
- currently set to 256
Block device 253:1

Now, let’s create the ext4 filesystems:

root@server ~ # mkfs.ext4 /dev/vg00/vol_backups
mke2fs 1.45.5 (07-Jan-2020)
Creating filesystem with 131072000 4k blocks and 32768000 inodes
Filesystem UUID: 9decc28e-dae7-469f-b1de-7d6da1fd5fb0
Superblock backups stored on blocks:
32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632, 2654208,
4096000, 7962624, 11239424, 20480000, 23887872, 71663616, 78675968,
102400000

Allocating group tables: done
Writing inode tables: done
Creating journal (262144 blocks): done
Writing superblocks and filesystem accounting information: done

root@server ~ # mkfs.ext4 /dev/vg00/vol_media
mke2fs 1.45.5 (07-Jan-2020)
Creating filesystem with 7682409472 4k blocks and 480151552 inodes
Filesystem UUID: 5b262682-ba8e-4e03-98c2-c742ccebdff8
Superblock backups stored on blocks:
32768, 98304, 163840, 229376, 294912, 819200, 884736, 1605632, 2654208,
4096000, 7962624, 11239424, 20480000, 23887872, 71663616, 78675968,
102400000, 214990848, 512000000, 550731776, 644972544, 1934917632,
2560000000, 3855122432, 5804752896

Allocating group tables: done
Writing inode tables: done
Creating journal (262144 blocks): done
Writing superblocks and filesystem accounting information: done

In order to mount our new volumes, we have to create some identifiers:

root@server ~ # blkid /dev/vg00/vol_backups
/dev/vg00/vol_backups: UUID="9decc28e-dae7-469f-b1de-7d6da1fd5fb0" TYPE="ext4"
root@server ~ # blkid /dev/vg00/vol_media
/dev/vg00/vol_media: UUID="5b262682-ba8e-4e03-98c2-c742ccebdff8" TYPE="ext4"

Now, we can mount the volumes.
